MicoAir MG-902 GPS with compass
Package Includes
- 1x GPS module
- 1x Interconnect cable
₹1,699.00 inc. GST
ETA:6 days
Your Payment is 100% Secure
The MicoAir MG-902 is a GPS module featuring a U-Blox M9 chip and a QMC5883L compass, available at an affordable price. The M9 chip supports all L1 GNSS signals (GPS, GLONASS, Galileo, BeiDou) and can lock onto up to 32 satellites. Its biggest advantage is the high refresh rate of up to 25Hz. The GPS module features a 25x25x4 mm patch antenna for strong signal reception.
An LED indicates the status of the GPS module. The blue LED is constantly lit when powered on and blinks once a 3D fix is acquired.
Key Features
- Input voltage: 5V
- GNSS chip: U-BLOX M9 (M9140)
- Magnetic Compass: QMC5883L
- Antenna: 25x25x4 mm
- Max Navigation rate: 25Hz
- Tracking Sensitivity: -167 dBm
- Maximum Number of Satellites: 32
- Concurrent: 4 (GPS/BeiDou/Galileo/GLONASS)
- Size: 25x25x8 mm
- Weight: 12g
- Conector: SH1.0-6P
Package Includes
- 1x GPS module
- 1x Interconnect cable
| Weight | 0.012 kg |
|---|---|
| Dimensions | 2.5 × 2.5 × 0.4 cm |
