Axisflying Brushless Motor C224 2204.5 2300KV For 3.5inch Cinewhoop And Cinematic Drone

*Specs

– 2300KV is for 6S

– Configuration: 12N14P / N52H arc magnet

– Motor stator size: 2204.5

– Motor mounting hole size: 4*M2 (Φ12mm)

– Motor cables: AWG 20#, 150MM

– Motor dimensions (Dia *Len): Φ26.9*28.8MM  / M5 shaft

– Motor weight (including 150MM cables) : 21g

– The motor is very powerful that can get over 0.85KG and most current is about 25A

*Package

– 1* C224 motor

– 4* M2*5 screws for motor

– 1* M3*4 screw for lock shaft

– 1* M5 Flanged Nylon Insert lock nut

– 1* O-ring

– 1* Washer

Original price was: ₹1,999.00.Current price is: ₹1,799.00. inc. GST

Categories:
Guaranteed safe checkout Pay safely with Visa Pay safely with Master Card Pay safely with American Express Pay safely with PayPal
Your Payment is 100% Secure

AxisFlying’s C224 motors will deliver all the torque and power your 3.5″ Cinewhoop craves!

Equipped with a longer M5 shaft to secure the attachment of the propellers, the C224 is also protected from dust and rain thanks to its IP53 index.

SPECIFICATIONS



  • KV: 2300
  • Internal resistance: 76.7mΩ
  • Shaft diameter: 5mm
  • Rated voltage: 4-6S
  • Max power: 567.8W
  • Configuration : 12N14P
  • Dimensions : ⌀26.9*28.8mm
  • Silicone wire : 20#150mm
  • Weight: 21g (without cable)
  • Peak current: 24.09A

INCLUDED



  • 1x C224 motor



Axisflying fpv brushless motor C224 2204.5 for 3.5inch cinewhoop and cinematic drone Axisflying fpv C224 2204.5 brushless motors for 3.5inch cinewhoop and cinematic drone brushless motor,fpv motor,cinematic motor,cinewhoop motor,indoor motor,7inch longrange motor,cinelifter X8 motor,longrang motor,freestyle motor,5inch drone motor,top quality motor,racing motor,dji motor,2306 motor,2207 motor,1507 motor,2204.5 motor,2004 motor,2807.5 motor,3010 motor,1303.5 motor,1404.5 motor,DJI motors,5inch motor,6inch motor,7inch motor,2inch motor,2.5inch motor,3inch motor,3.5inch motor,fpv quads motor,drone motors

Weight 0.12 kg
Dimensions 10 × 10 × 10 cm
